MIL-DTL-15665/114
DIMENSIONS:
EAGLE AND SHIELD:
HEIGHT: 15/16 inch (REF)
WIDTH (At wing tips): 7/8 inch (REF)
THICKNESS (Edge of Shield): 0.075 inch + 0.010 inch
DEVICE:
HEIGHT: 1/4 inch (REF)
WIDTH: 17/64inch (REF)
Thickness (Edge of shield): 0.080 inch + 0.010 Inch
ATTACHING DEVICE:
1. Attaching device should be prong and wing type clutch.
2. Prongs should be located on the vertical center line equidistant from each end and
5/8 inch + 1/64 apart.
EPOXY: Epoxy shall be applied as indicated above and as specified in the table below, and
shall match the TIOH Hard Enamel Color Chip Number listed. Hard cloisonné enamel may
be used in lieu of epoxy enamel. If hard Cloisonné enamel is used, the required base
material for -1 and -2 shall be Gilding Metal 95/5 (UNS Alloy C-210):
TIOH HARD ENAMEL
ITEM
LOCATION
COLOR CHIP NUMBER
Blue #18
-1, -2
Shield, as indicated in the above drawing
Blue #20
-1, -2
Shield, as indicated in the above drawing
NOTES:
1. The term (REF) refers to the measurements taken from the Government furnished hub or
die.
2. The device should be superimposed and secured to the shield by two rivets or soft
soldered. When rivets are used, they should be solid and fabricated from any type.
brass. The rivets should be located on and soldered to the vertical center line of the
device. The device should be located on the insignia as indicated.
3. Eagle on Shield will be modeled.
Page 2 of 3
