INCH-POUND
MIL-DTL-1563/2B
6 January 2014
SUPERSEDING
MIL-DTL-1563/2A
30 April 1997
DETAIL SPECIFICATION SHEET
INSIGNIA, U.S.M.A., SERVICE CAP, UNIFORM
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this specification
sheet and the latest issue of MIL-DTL-1563.
MATERIAL: Red Brass 85/15 (UNS Alloy No. C-230)
FINISH: Gold Plated, Matte Finish, Burnished Highlights.
MARKING FOR IDENTIFICATION: Back of Insignia
DIMENSIONS:
HEIGHT (At highest point): 2-13/32 inch (REF)
WIDTH (At Widest Point): 2-23/32 inch (REF)
THICKNESS (Eagle head): 0.064 inch + 0.005 inch
AMSC N/A
Page 1 of 2
FSC 8455
