MIL-DTL-11589/470A
COLOR PATTERN: MINIATURE SIZE
FINISH: PLAIN
TOTAL
WIDTH OF STRIPES
FUNCTION
COLOR & CABLE NUMBER
WIDTH
INCHES & METRIC
OF STRIPES
STRIPES
FILLING YARN
1/32
0.8mm
Edge & Binder
Irish Green
HCO 67189
1/32
0.8mm
Ground
Irish Green
HCO 67189
1/64
0.4mm
Ground
White
HA
67101
1/32
0.8mm
Ground
Ultramarine Blue
HS
67118
1/16
1.6mm
Ground
White
HA
67101
1/32
0.8mm
Ground
Ultramarine Blue
HS
67118
1/64
0.4mm
Ground
White
HA
67101
3/64
1.2mm
Ground
Irish Green
HCO 67189
1/64
0.4mm
Ground
White
HA
67101
11/16"
1/32
0.8mm
Ground
Ultramarine Blue
HS
67118
White
(17.5mm)
1/16
1.5mm
Ground
White
HA
67101
HA 67101
1/32
0.8mm
Ground
Ultramarine Blue
HS
67118
1/64
0.4mm
Ground
White
HA
67101
3/64
1.2mm
Ground
Irish Green
HCO 67189
1/64
0.4mm
Ground
White
HA
67101
1/32
0.8mm
Ground
Ultramarine Blue
HS
67118
1/16
1.6mm
Ground
White
HA
67101
1/32
0.8mm
Ground
Ultramarine Blue
HS
67118
1/64
0.4mm
Ground
White
HA
67101
1/32
0.8mm
Ground
Irish Green
HCO 67189
1/32
0.8mm
Edge & Binder
Irish Green
HCO 67189
NOTE: This item is not authorized for commercial sale, and may be produced only under Government
contract.
CHANGES FROM PREVIOUS ISSUE: The margins of this specification are marked with vertical
lines to indicate where changes from the previous issue were made. This was done as a
convenience only and the Government assumes no liability whatsoever for any inaccuracies in these
notations. Bidders and contractors are cautioned to evaluate the requirements of this document
based on the entire content irrespective of the marginal notations and relationship to the last previous
issue.
Custodian:
Preparing activity:
Army - IH
Army - IH
Review activity:
DLA - CT
Civil agency:
(Project No. 8455-2010-281)
DOE
NOTE: The activities listed above were interested in this document as of the date of this document. Since
organizations and responsibilities can change, you should verify the currency of the information above
using the ASSIST Online database at https://assist.daps.dla.mil.
Page 2 of 2
