MIL-DTL-11589/47E
COLOR PATTERN
SIZE: MINIATURE
FINISH: MOIRE
COLOR & CABLE NUMBER
TOTAL
WIDTH OF
FUNCTION
FILLING
WIDTH
STRIPES INCHES
OF STRIPES
STRIPES
YARN
1/32
Edge & Binder
Ultramarine Blue
HS
67118
1/32
Ground
Ultramarine Blue
HS
67118
1/16
Ground
White
HA
67101
11/64
Ground
Ultramarine Blue
HS
67118
3/128
Ground
White
HA
67101
White
11/16"
3/64
Ground
Old Glory Red
HBF
67156
HA 67101
3/128
Ground
White
HA
67101
11/64
Ground
Ultramarine Blue
HS
67118
1/16
Ground
White
HA
67101
1/32
Ground
Ultramarine Blue
HS
67118
1/32
Edge & Binder
Ultramarine Blue
HS
67118
