MIL-DTL-11589/4F
COLOR PATTERN: MINIATURE SIZE
FINISH: MOIRÉ
TOTAL
WIDTH OF STRIPES
FUNCTION
COLOR & CABLE NUMBER
WIDTH
INCHES & METRIC
OF STRIPES
STRIPES
FILLING YARN
1/32
0.8mm
Edge & Binder
Old Glory Red
HBF
67156
1/32
0.8mm
Ground
Old Glory Red
HBF
67156
1/32
0.8mm
Ground
White
HA
67101
3/16
4.8mm
Ground
Old Glory Blue
HCC 67178
11/16"
1/32
0.8mm
Ground
White
HA
67101
White
(17.5mm)
1/16
1.5mm
Ground
Old Glory Red
HBF
67156
HA 67101
1/32
0.8mm
Ground
White
HA
67101
3/16
4.8mm
Ground
Old Glory Blue
HCC 67178
1/32
0.8mm
Ground
White
HA
67101
1/32
0.8mm
Ground
Old Glory Red
HBF
67156
1/32
0.8mm
Edge & Binder
Old Glory Red
HBF
67156
COLOR PATTERN: STREAMER SIZE
FINISH: MOIRÉ
TOTAL
WIDTH OF STRIPES
FUNCTION
COLOR & CABLE NUMBER
WIDTH
INCHES & METRIC
OF STRIPES
STRIPES
FILLING YARN
1/32
0.8mm
Edge & Binder
Old Glory Red
HBF
67156
7/32
5.6mm
Ground
Old Glory Red
HBF
67156
1/8
3.2mm
Ground
White
HA
67101
3/4
19.0mm
Ground
Old Glory Blue
HCC 67178
2-3/4"
1/8
3.2mm
Ground
White
HA
67101
White
(70.0mm)
1/4
6.4mm
Ground
Old Glory Red
HBF
67156
HA 67101
1/8
3.2mm
Ground
White
HA
67101
3/4
19.0mm
Ground
Old Glory Blue
HCC 67178
1/8
3.2mm
Ground
White
HA
67101
7/32
5.6mm
Ground
Old Glory Red
HBF
67156
1/32
0.8mm
Edge & Binder
Old Glory Red
HBF
67156
