MIL-DTL-11589/375D
CT LOR PATTERN: MINIATURE SIZE
O
FINISH: MOIRE
OTAL
WIDTH OF STRIPES
FUNCTION
COLOR
& CABLE NUMBER
WIDTH
INCHES & METRIC
OF STRIPES
STRIPES
FILLING YARN
1/32
0.8mm
Edge & Binder
Old Glory Blue
HCC 67178
3/64
1.2mm
Ground
Old Glory Blue
HCC 67178
5/64
2.0mm
Ground
White
HA
67101
1/32
0.8mm
Ground
Old Glory Blue
HCC 67178
1/64
0.4mm
Ground
White
HA
67101
11/16"
1/16
1.6mm
Ground
Old Glory Blue
HCC 67178
White
(17.5mm)
5/32
3.9mm
Ground
White
HA
67101
HA 67101
1/16
1.6mm
Ground
Old Glory Blue
HCC 67178
1/64
0.4mm
Ground
White
HA
67101
1/32
0.8mm
Ground
Old Glory Blue
HCC 67178
5/64
2.0mm
Ground
White
HA
67101
3/64
1.2mm
Ground
Old Glory Blue
HCC 67178
1/32
0.8mm
Edge & Binder
Old Glory Blue
HCC 67178
NOTE:
This item is not authorized for commercial sale, and may be produced only under Government
contract.
CHANGES FROM PREVIOUS ISSUE: The margins of this specification are marked with vertical
lines to indicate where changes from the previous issue were made. This was done as a
convenience only and the Government assumes no liability whatsoever for any inaccuracies in
these notations. Bidders and contractors are cautioned to evaluate the requirements of this
document based on the entire content irrespective of the marginal notations and relationship to the
last previous issue.
Custodians:
Preparing activity:
Army - IH
Army - IH
Review activities:
DLA - CT
Civil Agency Coordinating activities:
(Project No. 8455-2010-187)
DOJ - BOP
FPI
NOTE: The activities listed above were interested in this document as of the date of this document. Since
organizations and responsibilities can change, you should verify the currency of the information above using
the ASSIST Online database at https://assist.daps.dla.mil.
Page 2 of 2
