MIL-DTL-11589/317D
COLOR PATTERN: MINIATURE SIZE
FINISH: MOIRE
TOTAL
WIDTH OF STRIPES
FUNCTION
COLOR & CABLE NUMBER
WIDTH
INCHES & METRIC
OF STRIPES
STRIPES
FILLING YARN
1/32
0.8 mm
Edge & Binder
Imperial Purple
HBL 67161
1/16
1.6mm
Ground
Imperial Purple
HBL 67161
1/32
0.8 mm
Ground
White
HA
67101
1/8
3.2mm
Ground
Bluebird
HR
67117
11/16"
1/32
0.8 mm
Ground
White
HA
67101
White
(17.5 mm)
1/8
3.1mm
Ground
Flag Blue
HY
67124
HA 67101
1/32
0.8 mm
Ground
White
HA
67101
1/8
3.2mm
Ground
Bluebird
HR
67117
1/32
0.8 mm
Ground
White
HA
67101
1/16
1.6mm
Ground
Imperial Purple
HBL
67161
1/32
0.8 mm
Edge & Binder
Imperial Purple
HBL
67161
CHANGES FROM PREVIOUS ISSUE: Marginal notations are not used in this revision to identify
changes with respect to the previous issue due to the extent of the changes.
