NOT MEASUREMENT SENSITIVE
MIL-DTL-11589/315E
15 September 1995
SUPERSEDING
MIL-R-11589/315D
28 March 1994
DETAIL SPECIFICATION SHEET
RIBBON, SURGEON GENERAL'S MEDALLION, U.S. PUBLIC HEALTH SERVICE
This specification is approved for use by all Departments and Agencies
of the Department of Defense
The requirements for acquiring the product described herein shall consist of
this specification sheet and the issue of MIL-DTL-11589 listed in that issue of the
Department of Defense Index of Specifications and Standards (DoDISS) specified in
the solicitation.
COLOR PATTERN
SIZE: Regular
FINISH: Moire___
| TOTAL |WIDTH OF STRIPES| FUNCTION OF
|
COLOR
& CABLE NUMBER
|
| WIDTH |INCHES & METRIC |
STRIPES
|
STRIPES
| FILLING YARN |
|
|1/32
(0.8 mm)| Edge & Binder
|Golden Yellow
HD 67104|
|
|
|3/32
(2.4 mm)|
Ground
|Golden Yellow
HD 67104|
|
|
|5/16
(7.9 mm)|
Ground
|Ultramarine Blue
HS 67118|
|
|
|1/16
(1.6 mm)|
Ground
|Golden Yellow
HD 67104|
|
|
|1/8
(3.2 mm)|
Ground
|Ultramarine Blue
HS 67118|
|
| 1-3/8
|1/8
(3.2 mm)|
Ground
|Golden Yellow
HD 67104| White HA 67101 |
|(35.0 mm)|1/8
(3.2 mm)|
Ground
|Ultramarine Blue
HS 67118|
|
|
|1/16
(1.6 mm)|
Ground
|Golden Yellow
HD 67104|
|
|
|5/16
(7.9 mm)|
Ground
|Ultramarine Blue
HS 67118|
|
|
|3/32
(2.4 mm)|
Ground
|Golden Yellow
HD 67104|
|
|
|1/32
(0.8 mm)| Edge & Binder
|Golden Yellow
HD 67104|
|
|
|
|
|
|
|
COLOR PATTERN
SIZE: Miniature
FINISH: Moire___
| TOTAL |WIDTH OF STRIPES| FUNCTION OF
|
COLOR
& CABLE NUMBER
|
| WIDTH |INCHES & METRIC |
STRIPES
|
STRIPES
| FILLING YARN |
|
|1/32
(0.8 mm)| Edge & Binder
|Golden Yellow
HD 67104|
|
|
|1/32
(0.8 mm)|
Ground
|Golden Yellow
HD 67104|
|
|
|5/32
(4.0 mm)|
Ground
|Ultramarine Blue
HS 67118|
|
|
|1/32
(0.8 mm)|
Ground
|Golden Yellow
HD 67104|
|
|
|1/16
(1.6 mm)|
Ground
|Ultramarine Blue
HS 67118|
|
| 11/16
|1/16
(1.5 mm)|
Ground
|Golden Yellow
HD 67104| White HA 67101 |
|(17.5 mm)|1/16
(1.6 mm)|
Ground
|Ultramarine Blue
HS 67118|
|
|
|1/32
(0.8 mm)|
Ground
|Golden Yellow
HD 67104|
|
|
|5/32
(4.0 mm)|
Ground
|Ultramarine Blue
HS 67118|
|
|
|1/32
(0.8 mm)|
Ground
|Golden Yellow
HD 67104|
|
|
|1/32
(0.8 mm)| Edge & Binder
|Golden Yellow
HD 67104|
|
|
|
|
|
|
|
AMSC N/A
FSC 8455
DISTRIBUTION STATEMENT A.
Approved for public release; distribution is unlimited.
1 of 2
