INCH-POUND
MIL-DTL-11589/293D
24 July 2013
SUPERSEDING
MIL-DTL-11589/293C
15 September 1995
DETAIL SPECIFICATION SHEET
RIBBON, JOINT SERVICE ACHIEVEMENT MEDAL, DEPARTMENT OF DEFENSE
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this specification sheet
and the latest issue of MIL-DTL-11589.
COLOR PATTERN: REGULAR SIZE
FINISH: MOIRÉ
WIDTH OF
TOTAL
FUNCTION
COLOR & CABLE NUMBER
STRIPES
WIDTH
INCHES & METRIC
OF STRIPES
STRIPES
FILLING YARN
1/32
0.8 mm
Edge & Binder
Old Glory Blue
HCC
67178
3/32
2.4 MM
Ground
Old Glory Blue
HCC
67178
1/16
1.6 MM
Ground
White
HA
67101
1/8
3.2 MM
Ground
Green
HAD
67129
1/16
1.6 MM
Ground
White
HA
67101
1-3/8"
White
9/32
7.1 MM
Ground
Bluebird
HR
67117
35.0 mm
HA 67101
1/16
1.6 MM
Ground
Old Glory Red
HBF
67156
mm
9/32
7.1 MM
Ground
Bluebird
HR
67117
1/16
1.6 MM
Ground
White
HA
67101
1/8
3.2 MM
Ground
Green
HAD
67129
Ground
1/16
1.6 MM
White
HA
67101
Ground
3/32
2.4 MM
Ground
Old Glory Blue
HCC
67178
1/32
0.8 mm
Edge & Binder
Old Glory Blue
HCC
67178
AMSC N/A
Page 1 of 2
FSC 8455
