INCH-POUND
MIL-DTL-11589/289D
17 August 2010
SUPERSEDING
MIL-DTL-11589/289C
15 September 1995
DETAIL SPECIFICATION SHEET
RIBBON, JOINT MERITORIOUS UNIT AWARD,
DEPARTMENT OF DEFENSE
This specification is approved for use by all
Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet
and the latest issue of MIL-DTL-11589.
COLOR PATTERN: REGULAR SIZE
FINISH: MOIRÉ
TOTAL
WIDTH OF STRIPES
FUNCTION
COLOR & CABLE NUMBER
WIDTH
INCHES & METRIC
OF STRIPES
STRIPES
FILLING YARN
1/32
0.8mm
Edge & Binder
Bluebird
HR
67117
5/32
3.9mm
Ground
Bluebird
HR
67117
1/8
3.2mm
Ground
Golden Yellow
HD
67104
3/16
4.8mm
Ground
Bluebird
HR
67117
1-3/8"
1/8
3.2mm
Ground
White
HA
67101
White
(35.0mm)
1/8
3.2mm
Ground
Crimson
HM
67112
HA 67101
1/8
3.2mm
Ground
White
HA
67101
3/16
4.8mm
Ground
Bluebird
HR
67117
1/8
3.2mm
Ground
Golden Yellow
HD
67104
5/32
3.9mm
Ground
Bluebird
HR
67117
1/32
0.8mm
Edge & Binder
Bluebird
HR
67117
AMSC N/A
Page 1 of 2
FSC 8455
