INCH-POUND
MIL-DTL-11589/246E
19 July 2011
SUPERSEDING
MIL-DTL-11589/246D
15 September 1995
DETAIL SPECIFICATION SHEET
RIBBON, ACHIEVEMENT AWARD, U.S. PUBLIC HEALTH SERVICE
This specification is approved for use by all Departments and Agencies
of the Department of Defense
The requirements for acquiring the product described herein shall consist of this specification sheet
and the latest issue of MIL-DTL-11589.
COLOR PATTERN
SIZE: Regular
FINISH: Moiré
WIDTH OF
COLOR & CABLE NUMBER
STRIPES
TOTAL
FUNCTION
INCHES
METRIC
STRIPES
FILLING YARN
WIDTH
OF STRIPES
1/32
0.8 mm
Edge & Binder
Navy Blue #1
HCD
67179
3/32
2.4 mm
Ground
Navy Blue #1
HCD
67179
7/16
11.1 mm
Ground
Maroon
HO
67114
1-3/8
1/4
6.4 mm
Ground
Bluebird
HR
67117
White HA
(35.0mm) 7/16
11.1 mm
Ground
Maroon
HO
67114
67101
3/32
2.4 mm
Ground
Navy Blue #1
HCD
67179
1/32
0.8 mm
Edge & Binder
Navy Blue #1
HCD
67179
COLOR PATTERN
SIZE: Miniature
FINISH: Moiré
WIDTH OF
COLOR & CABLE NUMBER
STRIPES
FUNCTION
TOTAL
INCHES
METRIC
STRIPES
FILLING YARN
OF STRIPES
WIDTH
1/32
0.8 mm
Edge & Binder
Navy Blue #1
HCD
67179
1/32
0.8 mm
Ground
Navy Blue #1
HCD
67179
7/32
5.6 mm
Ground
Maroon
HO
67114
11/16
1/8
3.1 mm
Ground
Bluebird
HR
67117
White HA
(17.5mm) 7/32
5.6 mm
Ground
Maroon
HO
67114
67101
1/32
0.8 mm
Ground
Navy Blue #1
HCD
67179
1/32
0.8 mm
Edge & Binder
Navy Blue #1
HCD
67179
ASMC N/A
Page 1 of 2
FSC 8455
