MIL-DTL-11589/196D
3 May 2010
SUPERSEDING
MIL-DTL-11589/196C
15 September 1995
DETAIL SPECIFICATION SHEET
RIBBON, U.S. ARMY RESERVE COMPONENTS ACHIEVEMENT MEDAL
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this specification sheet
and the latest issue of MIL-DTL-11589.
COLOR PATTERN: REGULAR SIZE
FINISH: MOIRÉ
TOTAL
WIDTH OF STRIPES
FUNCTION
COLOR & CABLE NUMBER
WIDTH
INCHES & METRIC
OF STRIPES
STRIPES
FILLING YARN
1/32
0.8mm
Edge & Binder
Old Gold
HE
67105
9/32
7.1mm
Ground
Old Gold
HE
67105
1/8
3.2mm
Ground
Ultramarine Blue
HS
67118
1-3/8"
1/16
1.6mm
Ground
White
HA
67101
White
(35.0mm)
3/8
9.6mm
Ground
Scarlet
HL
67111
HA 67101
1/16
1.6mm
Ground
White
HA
67101
1/8
3.2mm
Ground
Ultramarine Blue
HS
67118
9/32
7.1mm
Ground
Old Gold
HE
67105
1/32
0.8mm
Edge & Binder
Old Gold
HE
67105
COLOR PATTERN: MINIATURE SIZE
FINISH: MOIRÉ
TOTAL
WIDTH OF STRIPES
FUNCTION
COLOR & CABLE NUMBER
WIDTH
INCHES & METRIC
OF STRIPES
STRIPES
FILLING YARN
1/32
0.8mm
Edge & Binder
Old Gold
HE
67105
1/8
3.2mm
Ground
Old Gold
HE
67105
1/16
1.6mm
Ground
Ultramarine Blue
HS
67118
11/16"
1/32
0.8mm
Ground
White
HA
67101
White
(17.5mm)
3/16
4.7mm
Ground
Scarlet
HL
67111
HA 67101
1/32
0.8mm
Ground
White
HA
67101
1/16
1.6mm
Ground
Ultramarine Blue
HS
67118
1/8
3.2mm
Ground
Old Gold
HE
67105
1/32
0.8mm
Edge & Binder
Old Gold
HE
67105
