INCH-POUND
MIL-DTL-11589/169F
16 June 2010
SUPERSEDING
MIL-DTL-11589/169E
15 September 1995
DETAIL SPECIFICATION SHEET
RIBBON, AWARD FOR VALOR, FEDERAL AVIATION ADMINISTRATION
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this specification sheet
and the latest issue of MIL-DTL-11589.
COLOR PATTERN: REGULAR SIZE
FINISH: MOIRÉ
TOTAL
WIDTH OF STRIPES
FUNCTION
COLOR & CABLE NUMBER
WIDTH
INCHES & METRIC
OF STRIPES
STRIPES
FILLING YARN
1/32
0.8mm
Edge & Binder
Paprica
HBA
67151
3/32
2.4mm
Ground
Paprica
HBA
67151
1/16
1.6mm
Ground
Golden Yellow
HD
67104
1-3/8"
13/32
10.3mm
Ground
Paprica
HBA
67151
Golden Yellow
(35.0mm)
3/16
4.8mm
Ground
Golden Yellow
HD
67104
HD 67104
13/32
10.3mm
Ground
Paprica
HBA
67151
1/16
1.6mm
Ground
Golden Yellow
HD
67104
3/32
2.4mm
Ground
Paprica
HBA
67151
1/32
0.8mm
Edge & Binder
Paprica
HBA
67151
NOTE: This item is not authorized for commercial sale, and may be produced only under
Government contract.
CHANGES FROM PREVIOUS ISSUE: The margins of this specification are marked with vertical
lines to indicate where changes from the previous issue were made. This was done as a
convenience only and the Government assumes no liability whatsoever for any inaccuracies in
these notations. Bidders and contractors are cautioned to evaluate the requirements of this
document based on the entire content irrespective of the marginal notations and relationship to the
last previous issue.
AMSC N/A
Page 1 of 2
FSC 8455
