INCH-POUND
MIL-DTL-11589/168E
09 October 2012
SUPERSEDING
MIL-DTL-11589/168D
15 September 1995
DETAIL SPECIFICATION SHEET
RIBBON, FRENCH NAVAL WAR
This specification is approved for use by all
Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet
and the latest issue of MIL-DTL-11589.
COLOR PATTERN: STREAMER SIZE
FINISH: MOIRÉ
TOTAL
WIDTH OF STRIPES
FUNCTION
COLOR & CABLE NUMBER
WIDTH
INCHES & METRIC
OF STRIPES
STRIPES
FILLING YARN
1/32
0.8mm
Edge & Binder
Grotto Blue
HBP 67165
11/32
8.7 mm
Ground
Grotto Blue
HBP 67165
9/32
7.1 mm
Ground
Scarlet
HL
67111
1/4
6.4 mm
Ground
White
HA
67101
2-3/4"
7/32
5.6 mm
Ground
Cobalt Blue
HW
67122
White
(70.0mm)
1/2
12.8 mm
Ground
Grotto Blue
HBP 67165
HA 67101
7/32
5.6 mm
Ground
Cobalt Blue
HW
67122
1/4
6.4 mm
Ground
White
HA
67101
9/32
7.1 mm
Ground
Scarlet
HL
67111
11/32
8.7 mm
Ground
Grotto Blue
HBP 67165
1/32
0.8mm
Edge & Binder
Grotto Blue
HBP 67165
CHANGES FROM PREVIOUS ISSUE: The margins of this specification are marked with vertical lines to
indicate where changes from the previous issue were made. This was done as a convenience only and
the Government assumes no liability whatsoever for any inaccuracies in these notations. Bidders and
contractors are cautioned to evaluate the requirements of this document based on the entire content
irrespective of the marginal notations and relationship to the last previous issue.
AMSC N/A
Page 1 of 2
FSC 8455
