INCH-POUND
MIL-DTL-11589/143E
9 June 2010
SUPERSEDING
MIL-DTL-11589/143D
15 September 1995
DETAIL SPECIFICATION SHEET
RIBBON, SUPERIOR CADET AWARD, ROTC (MILITARY SCHOOL DIVISION)
This specification is approved for use by all
Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet
and the latest issue of MIL-DTL-11589.
RIBBON SIZE: Regular
WIDTH: 1-3/8 inch + 1/16 inch - 0 (35.0 mm + 1.6 mm - 0)
TOTAL WARP ENDS (Minimum): 448
PICKS PER INCH (Minimum): 40 (2 threads single shot)
WEIGHT PER LINEAR YARD: 0.0175 pound
LINEAR BREAKING STRENGTH FULL WIDTH (Minimum): 100 pounds
COLOR PATTERN: REGULAR SIZE
FINISH: MOIRÉ
TOTAL
WIDTH OF STRIPES
FUNCTION
COLOR & CABLE NUMBER
WIDTH
INCHES & METRIC
OF STRIPES
STRIPES
FILLING YARN
3/16
4.8mm
Solid Ground
Scarlet
HL
67111
*See Note Below
3/16
4.8mm
White
HA
67101
Ultramarine Blue
HS
67118
1-3/8"
Scarlet
5/8
15.8mm
Solid Ground
Scarlet
HL
67111
(35.0mm)
HL 67111
*See Note Below
3/16
4.8mm
White
HA
67101
Ultramarine Blue
HS
67118
3/16
4.8mm
Solid Ground
Scarlet
HL
67111
AMSC N/A
Page 1 of 2
FSC 8455
