INCH-POUND
MIL-DTL-11589/141F
15 March 2012
SUPERSEDING
MIL-DTL-11589/141E
9 June 2010
DETAIL SPECIFICATION SHEET
RIBBON, SUPERIOR CADET AWARD, ROTC (SENIOR DIVISION)
This specification is approved for use by all
Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet
and the latest issue of MIL-DTL-11589.
RIBBON SIZE: Regular
WIDTH: 1-3/8 inches + 1/16 inch - 0 (35.0 mm + 1.6 mm - 0)
TOTAL WARP ENDS (Minimum): 448
PICKS PER INCH (Minimum): 40 (2 threads single shot)
WEIGHT PER LINEAR YARD: 0.0175 pound
LINEAR BREAKING STRENGTH FULL WIDTH (Minimum): 100 pounds
COLOR PATTERN: REGULAR SIZE
FINISH: MOIRÉ
TOTAL
WIDTH OF STRIPES
FUNCTION
COLOR & CABLE NUMBER
WIDTH
INCHES & METRIC
OF STRIPES
STRIPES
FILLING YARN
3/16
4.8mm
* See Note Below
White
HA
67101
Ultramarine Blue
HS
67118
1-3/8"
White
1
25.4mm
Solid Ground
Old Glory Red
HBF
67156
(35.0mm)
HA 67101
3/16
4.8mm
* See Note Below
White
HA
67101
Ultramarine Blue
HS
67118
*NOTE: The warp and horizontal stripes shall be alternating, one (1) White HA 67101 end and one (1)
Ultramarine Blue HS 67118 end throughout. The weave for the White HA 67101 and Ultramarine
Blue HS 67118 will be 2/2 resulting in seven (7) alternate White HA 67101 and Ultramarine Blue HS
67118 stripes in each 3/8 inch (9.5mm) length of ribbon. The selvage shall have a catch cord for
firmness, designed so as to eliminate any looping of the filling yarn. The color of the catch cord shall be White
HA 67101.
AMSC N/A
Page 1 of 2
FSC 8455
