MIL-DTL-11589/114F
COLOR PATTERN: MINIATURE SIZE
FINISH: MOIRÉ
TOTAL
WIDTH OF STRIPES
FUNCTION
COLOR & CABLE NUMBER
WIDTH
INCHES & METRIC
OF STRIPES
STRIPES
FILLING YARN
1/32
0.8mm
Edge & Binder
White
HA
67101
1/32*
0.8mm
Ground
White
HA
67101
3/64
1.2mm
Ground
Scarlet
HL
67111
7/128*
1.4mm
Ground
White
HA
67101
3/64
1.2mm
Ground
Scarlet
HL
67111
7/128*
1.4mm
Ground
White
HA
67101
11/16"
3/64
1.2mm
Ground
Scarlet
HL
67111
White
(17.5mm)
1/16*
1.5mm
Ground
White
HA
67101
HA 67101
3/64
1.2mm
Ground
Scarlet
HL
67111
7/128*
1.4mm
Ground
White
HA
67101
3/64
1.2mm
Ground
Scarlet
HL
67111
7/128*
1.4mm
Ground
White
HA
67101
3/64
1.2mm
Ground
Scarlet
HL
67111
1/32*
0.8mm
Ground
White
HA
67101
1/32
0.8mm
Edge & Binder
White
HA
67101
*NOTE: Each White HA 67101 stripe (exclusive of Edge & Binder) shall have an Oriental Blue (Cable No. HBW
67172) stripe centered vertically. The Oriental Blue stripe shall be 1/128 inch (0.2mm) wide on the 11/16 inch
(17.5mm) ribbon.
