INCH-POUND
MIL-DTL-11589/104E
31 May 2010
SUPERSEDING
MIL-DTL-11589/104D
15 September 1995
DETAIL SPECIFICATION SHEET
RIBBON, EXPERT PISTOL SHOT, U.S. NAVY
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this specification sheet
and the latest issue of MIL-DTL-11589.
COLOR PATTERN: REGULAR SIZE
FINISH: MOIRÉ
TOTAL
WIDTH OF STRIPES
FUNCTION
COLOR & CABLE NUMBER
WIDTH
INCHES & METRIC
OF STRIPES
STRIPES
FILLING YARN
1/32
0.8mm
Edge & Binder
Graphite Blue
HCF
67181
1/8
3.2mm
Ground
Graphite Blue
HCF
67181
1-3/8"
1/32
0.8mm
Ground
Emerald
HAC
67128
Graphite Blue
(35.0mm)
1
25.4mm
Ground
Graphite Blue
HCF
67181
HCF 67181
1/32
0.8mm
Ground
Emerald
HAC
67128
1/8
3.2mm
Ground
Graphite Blue
HCF
67181
1/32
0.8mm
Edge & Binder
Graphite Blue
HCF
67181
COLOR PATTERN: MINIATURE SIZE
FINISH: MOIRÉ
TOTAL
WIDTH OF STRIPES
FUNCTION
COLOR & CABLE NUMBER
WIDTH
INCHES & METRIC
OF STRIPES
STRIPES
FILLING YARN
1/32
0.8mm
Edge & Binder
Graphite Blue
HCF
67181
3/64
1.2mm
Ground
Graphite Blue
HCF
67181
11/16"
1/64
0.4mm
Ground
Emerald
HAC
67128
Graphite Blue
(17.5mm)
1/2
12.7mm
Ground
Graphite Blue
HCF
67181
HCF 67181
1/64
0.4mm
Ground
Emerald
HAC
67128
3/64
1.2mm
Ground
Graphite Blue
HCF
67181
1/32
0.8mm
Edge & Binder
Graphite Blue
HCF
67181
