NOT MEASUREMENT SENSITIVE
MIL-DTL-11484/54E
27 September 1996
SUPERSEDING
MIL-L-11484/54D
14 January 1994
DETAIL SPECIFICATION SHEET
LAPEL BUTTON, AIR FORCE
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall
consist of this specification sheet and the issue of MIL-DTL-11484 listed in
that issue of the Department of Defense Index of Specifications and
Standards (DoDISS) specified in the solicitation.
MATERIAL:
Red Brass or Nickel Silver
FINISH:
Nickel Plated (Red Brass only), Silver Plated, Oxidized,
Relieved, Matte Finish and shall match TIOH Metal Finish Chip
Number 14.
DIMENSIONS:
HEIGHT (Overall): 5/8 inch (1.59 cm) (REF)
WIDTH (Overall):
7/32 inch (0.56 cm) (REF)
THICKNESS (At Eagle's Breast): 0.070 inch + 0.010 inch (0.178 cm +
0.025 cm)
AMSC N/A
FSC 8455
DISTRIBUTION STATEMENT A.
Approved for public release; distribution is unlimited.
1 of 2
