INCH-POUND
MIL-DTL-11484/366
13 January 2015
DETAIL SPECIFICATION SHEET
LAPEL BUTTON, THE SPIRIT OF HOPE AWARD, U.S. DEPARTMENT OF DEFENSE
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this specification
sheet and the latest issue of MIL-DTL-11484.
MATERIAL: Red Brass 85/15 (UNS Alloy No. C-230)
FINISH: Brass, Oxidized, Buffed Relieved and shall match The Institute of Heraldry Metal
Finish Chip number 4.
DIMENSIONS:
DIAMETER: 11/16 inch (REF)
THICKNESS: 0.063 inch ± 0.010 inch
ATTACHING DEVICE:
1. Attaching device shall be prong with pick and wing type clutch.
2. The prong shall be centered on the reverse side and fused or soldered to the lapel
button.
NOTES:
1: The term (REF) refers to the measurements taken from the Government furnished
hub or die.
2: These item are not authorized for commercial sale, and may be produced only under
Government contract and the request of the Department of Defense.
AMSC N/A
1 of 2
FSC 8455
