NOT MEASUREMENT SENSITIVE
MIL-DTL-11484/238
29 February 1996
DETAIL SPECIFICATION SHEET
LAPEL BUTTON, DISTINGUISHED SERVICE, NATIONAL RECONNAISSANCE OFFICE
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall
consist of this specification sheet and the issue of MIL-DTL-11484 listed in
that issue of the Department of Defense Index of Specifications and
Standards (DoDISS) specified in the solicitation.
MATERIAL:
Red Brass
FINISH:
Gold Plated, Matte Finish and shall match TIOH Metal Finish Chip
Number 7.
DIMENSIONS:
DIAMETER: 5/8 inch (1.59 cm) (REF)
Thickness (At Edge): 0.085 inch + 0.005 inch (2.06 cm + 0.12 cm)
NOTES:
1.
The term (REF) refers to the measurements taken from the
Government furnished hub or die.
AMSC N/A
FSC 8455
DISTRIBUTION STATEMENT A.
Approved for public release; distribution is unlimited.
1 of 2
