INCH-POUND
MIL-DTL-11484/225B
3 March 2010
SUPERSEDING
MIL-DTL-3628/225A
27 September 1996
DETAIL SPECIFICATION SHEET
LAPEL BUTTON, AERIAL ACHIEVEMENT MEDAL, CIVILIAN, AIR FORCE
This specification is approved for use by all
Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification
sheet and the latest issue of MIL-DTL-11484.
#8
#8
#33
#18
MATERIAL: Gilding Medal
DIMENSIONS:
HEIGHT (overall): 9/64 inch (REF)
WIDTH (overall): 21/32 inch (REF)
THICKNESS (at edge): 0.065 inch + 0.005 inch
FINISH: Hard Enameled, Nickel Plated, Mirror-like Polished and shall
match The Institute of Heraldry (TIOH) Metal Finish Chip Number 16.
NOTES:
1. The term (REF) refers to the measurements taken from the Government furnished
hub or die.
AMSC N/A
Page 1 of 2
FSC 8455
