INCH-POUND
MIL-DTL-11484/192D
2 MARCH 2007
SUPERSEDING
MIL-DTL-11484/192C
23 January 2007
DETAIL SPECIFICATION SHEET
LAPEL BUTTON, DISTINGUISHED SERVICE MEDAL, DEPARTMENT OF HOMELAND SECURITY
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall
consist of this specification sheet and the latest issue of MIL-DTL-11484.
Blue chip #33
White chip #28
Green chip #12
Scarlet chip #1
Blue chip #18
MATERIAL:
Gilding Medal
DIMENSIONS:
HEIGHT (Overall): 9/64 inch (0.36 cm) (REF)
WIDTH (Overall):
21/32 inch (1.67 cm) (REF)
THICKNESS (At Edge): 0.065 inch + 0.005 inch (0.165 cm + 0.012 cm)
FINISH:
Hard Enameled, Gold Plated, Mirror-like Polished and shall
match TIOH Metal Finish Chip Number 6.
1. The term (REF) refers to the measurements taken from the Government
furnished hub or die.
AMSC N/A
FSC 8455
1 of 2
