NOT MEASUREMENT SENSITIVE
MIL-DTL-11484/117D
26 October 1998
SUPERSEDING
MIL-DTL-11484/200B
27 September 1996
DETAIL SPECIFICATION SHEET
LAPEL BUTTON, NATIONAL INTELLIGENCE MEDAL OF ACHIEVEMENT
This specification is approved for use by all Departments and Agencies
of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this
specification sheet and the issue of MIL-DTL-11484 listed in that issue of the Department of
Defense Index of Specifications and Standards (DoDISS) specified in the solicitation.
DASH NO.
-1: Bar
-2: Emblem
FINISH:
-1: Hard Enameled, Gold Plated, Mirror-like Polished and shall match TIOH Metal
Finish Chip Number 6.
-2: Gold Plated, Rose Gold Plated, Relieved, Polished Highlights
DIMENSIONS:
DASH No. -1 (Bar):
HEIGHT (Overall): 9/64 inch (0.36 cm) (REF)
WIDTH (Overall): 21/32 inch (1.67 cm) (REF)
THICKNESS: 0.065 inch + 0.005 inch (0.165 cm + 0.012 cm)
AMSC N/A
FSC 8455
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
1 of 2
