INCH-POUND
MIL-DTL-11132/2G
16 October 2001
SUPERSEDING
MIL-DTL-11132/2F
6 June 1997
DETAIL SPECIFICATION SHEET
INSIGNIA, RANK, DISK, ROTC, ARMY
This specification is approved for use by all Departments and Agencies
of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this
specification sheet and the issue of MIL-DTL-11132 listed in that issue of the Department of
Defense Index of Specifications and Standards (DoDISS) specified in the solicitation.
DASH NO.
-1: Regular
MATERIAL: -1: Red Brass or Nickel Silver
-2: Subdued
-2: Red Brass or Zinc Aluminum
FINISH:
-1: Nickel Plated (Red Brass only), Mirror-like Polished and shall match The Institute
of Heraldry (TIOH) Metal Finish Chip Number 16.
-2: Dull, Flat Black Enamel.
DIMENSIONS:
DIAMETER: 3/4 inch ± 1/64 inch
THICKNESS: 0.040 inch ± 0.005 inch
AMSC N/A
1 of 2
FSC 8455
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
