MIL-DTL-11132/10F
DIMENSIONS:
HEIGHT (Overall):
-1: 2-1/4 inches (REF)
-2, -3: 1-3/16 inches (REF)
WIDTH (Overall)
-1: 1-5/16 inches (REF)
-2, -3: 11/16 inch (REF)
THICKNESS (Overall):
-1, -2: 0.070 inch + 0.010 inch
-3: 0.100 inch + 0.010 inch (Including Plastic Back Plate)
EPOXY: Epoxy resin shall be applied to the insignia rank as indicated above, and shall match
TIOH Hard Enamel Color Chip Numbers listed below. Hard cloisonné enamel may be used in
lieu of epoxy. If hard cloisonné enamel is used, the required base material shall be Gilding
Metal 95/5 (UNS Alloy C-210).
TIOH HARD ENAMEL COLOR CHIPS
COLOR
CHIP NUMBER
Blue
#18
ATTACHING DEVICE:
The attaching device shall be a prong clutch type as follows.
1. -1 shall have three prongs and clutches. One prong shall be located on the vertical
center line 3/16 inch + 1/32 inch below the top of the insignia and one prong in each of the
lower corners 3/16 inch + 1/32 inch in from the sides and up from the bottom.
2. -2 and -3 shall have two prongs located on the vertical center line of the insignia,
equidistant from each end and 3/4 inch + 1/32 inch apart.
NOTES:
1. The term (REF) refers to the measurements taken from the obverse Government furnished
hub or die.
2. -2 and -3 are identical with the exception of a plastic back plate which is added to designate
JROTC.
CHANGES FROM PREVIOUS ISSUE: Marginal notations are not used in this revision to
identify changes with respect to the previous issue due to the extent of the changes.
Page 2 of 3
