MIL-DTL-3628/85C
FINISH:
PENDANT:
-1: Oxidized, Buffed Relieved, Lacquered, Front, Back and Edges.
-2: Nickel Plated, Mirror-like Polished and shall match TIOH Metal Finish Chip Number 16.
SUSPENSION BAR:
-1: Oxidized, Buffed Relieved.
-2: Nickel Plated, Mirror-like Polished and shall match TIOH Metal Finish Chip Number 16.
DEVICE:
-1: Epoxy resin (Stoning epoxy), Oxidized, Buffed Relieved.
-2: Epoxy resin (Stoning epoxy), Nickel Plated, Mirror-like Polished and shall match TIOH
Metal Finish Chip Number 16.
DIMENSIONS:
PENDANT:
DIAMETER: 1-19/32 inches (REF)
THICKNESS: (Edge): 0.095 inch + 0.010 inch
SUSPENSION BAR:
HEIGHT (Overall): 11/32 inch (REF)
WIDTH (Overall): 1-9/32 inches (REF)
THICKNESS (Edge): 0.075 inch + 0.010 inch
DEVICE:
TARGET:
HEIGHT: 3/8 inch (REF)
WIDTH: 3/8 inch (REF)
THICKNESS: 0.050 inch + 0.005 inch
COAT OF ARMS:
HEIGHT: 5/8 inch (REF)
WIDTH: 3/8 inch (REF)
THICKNESS: 0.050 inch + 0.005 inch
EPOXY: Epoxy resin shall be applied to the Badge as indicated above, and shall match
TIOH Hard Enamel Color Chip Numbers listed below. Hard cloisonné enamel may be
used in lieu of epoxy. If hard cloisonné enamel is used, the required base material shall
be Gilding Metal 95/5 (UNS Alloy C-210).
TIOH HARD ENAMEL COLOR
CHIPS
COLOR
CHIP NUMBER
Blue
#18
White
#28
ATTACHING DEVICE AND LUGS:
1. The attaching device shall be prong and clutch type.
2. The prongs shall be located on the horizontal center line of the suspension bar
equidistant from each end and 1-1/4 inches + 1/32 inch apart.
