INCH-POUND
MIL-DTL-3943/23E
10 September 2007
SUPERSEDING
MIL-DTL-3943/23D
1 May 1997
DETAIL SPECIFICATION SHEET
DECORATION, AIR MEDAL
This specification is approved for use by all Departments and
Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification
sheet and the latest issue of MIL-DTL-3943.
OBVERSE
REVERSE
DASH NO.
-1: Regular Size
MATERIAL: Red Brass
-2: Miniature Size
FINISH: Oxidized, Buffed Relieved and shall match The Institute of Heraldry (TIOH) Metal
Finish Chip Number 4.
DIMENSIONS:
HEIGHT (overall):
-1: 2-3/16 inches (REF)
-2: 1-1/16 inches (REF)
AMSC N/A
1 of 2
FSC 8455
