INCH-POUND
MIL-DTL-14639/9H
8 February 2013
SUPERSEDING
MIL-DTL-14639/9G
1 October 1998
DETAIL SPECIFICATION SHEET
INSIGNIA, GRADE, SERGEANT MAJOR (E-9) U.S. ARMY
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this
specification sheet and the latest issue of MIL-DLT-14639
DASH NO.
-1: Subdued
-2: Bright
MATERIAL:
-1: Red Brass 85/15 (UNS Alloy No.C-230) Yellow Brass 65/35 (UNS Alloy C-268) or
Zinc Aluminum
-2: Red Brass 85/15 (UNS Alloy No. C-230)
FINISH:
-1: Baked, Dull Flat Black, and shall match The Institute of Heraldry (TIOH) Metal Finish
Chip Number 21.
-2: Brass Mirror-like Polished and shall match TIOH Metal Finish Chip Number 1.
AMSC N/A
Page 1 of 2
FSC 8455
