INCH-POUND
MIL-DTL-11589/286D
17 August 2010
SUPERSEDING
MIL-DTL-11589/286C
15 September 1995
DETAIL SPECIFICATION SHEET
RIBBON, OUTSTANDING CAREER ACHIEVEMENT AWARD,
U.S.A.I.D., U.S. DEPARTMENT OF STATE
This specification is approved for use by all
Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet
and the latest issue of MIL-DTL-11589.
COLOR PATTERN: REGULAR SIZE
FINISH: MOIRÉ
TOTAL
WIDTH OF STRIPES
FUNCTION
COLOR & CABLE NUMBER
WIDTH
INCHES & METRIC
OF STRIPES
STRIPES
FILLING YARN
1/32
0.8mm
Edge & Binder
Soldier Red
HBG 67157
3/32
2.3mm
Ground
Soldier Red
HBG 67157
1/8
3.2mm
Ground
Corsaire Blue
HCB
67177
1/16
1.6mm
Ground
White
HA
67101
1/8
3.2mm
Ground
Corsaire Blue
HCB
67177
1-3/8"
7/32
5.6mm
Ground
Bluebird
HR
67117
White
(35.0mm)
1/16
1.6mm
Ground
White
HA
67101
HA 67101
7/32
5.6mm
Ground
Bluebird
HR
67117
1/8
3.2mm
Ground
Corsaire Blue
HCB
67177
1/16
1.6mm
Ground
White
HA
67101
1/8
3.2mm
Ground
Corsaire Blue
HCB
67177
3/32
2.3mm
Ground
Soldier Red
HBG 67157
1/32
0.8mm
Edge & Binder
Soldier Red
HBG 67157
CHANGES FROM PREVIOUS ISSUE: The margins of this specification are marked with vertical
lines to indicate where changes from the previous issue were made. This was done as a
convenience only and the Government assumes no liability whatsoever for any inaccuracies in
these notations. Bidders and contractors are cautioned to evaluate the requirements of this
document based on the entire content irrespective of the marginal notations and relationship to the
last previous issue.
AMSC N/A
Page 1 of 2
FSC 8455
