NOT MEASUREMENT SENSITIVE
MIL-DTL-11484/51F
27 September 1996
SUPERSEDING
MIL-L-11484/51E
14 January 1994
DETAIL SPECIFICATION SHEET
LAPEL BUTTON, NAVAL RESERVE MEMBERSHIP
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall
consist of this specification sheet and the issue of MIL-DTL-11484 listed in
that issue of the Department of Defense Index of Specifications and
Standards (DoDISS) specified in the solicitation.
MATERIAL:
Red Brass
FINISH:
Gold Plated, Rose Gold Plated, Matte Finish and shall match TIOH
Metal Finish Chip Number 19.
DIMENSIONS:
HEIGHT (Overall): 9/16 inch (1.43 cm) (REF)
WIDTH (Overall):
15/16 inch (2.38 cm) (REF)
THICKNESS (At Edge): 0.040 inch + 0.005 inch (0.102 cm + 0.012 cm)
NOTES:
1. The term (REF) refers to the measurements taken from the
Government furnished hub or die.
AMSC N/A
FSC 8455
DISTRIBUTION STATEMENT A.
Approved for public release; distribution is unlimited.
1 of 2
