INCH-POUND
MIL-DTL-11484/224B
3 March 2010
SUPERSEDING
MIL-DTL-3628/224A
27 September 1996
DETAIL SPECIFICATION SHEET
LAPEL BUTTON, AIR MEDAL, CIVILIAN, AIR FORCE
This specification is approved for use by all
Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification
sheet and the latest issue of MIL-DTL-11484.
#7
#18
MATERIAL: Gilding Metal
FINISH: Hard Enameled, Nickel Plated, Mirror-like Polished and shall match
The Institute of Heraldry (TIOH) Metal Finish Chip Number 16.
DIMENSIONS:
HEIGHT (overall): 9/64 inch (REF)
WIDTH (overall): 21/32 inch (REF)
THICKNESS (at edge): 0.065 inch + 0.005 inch
NOTES:
1. The term (REF) refers to the measurements taken from the Government furnished
hub or die.
AMSC N/A
Page 1 of 2
FSC 8455
