NOT MEASUREMENT SENSITIVE
MIL-DTL-11484/184B
27 September 1996
SUPERSEDING
MIL-L-11484/184A
14 January 1994
DETAIL SPECIFICATION SHEET
LAPEL BUTTON, CIVILIAN SUPPORT FOR DESERT SHIELD/STORM, NAVY
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall
consist of this specification sheet and the issue of MIL-DTL-11484 listed in
that issue of the Department of Defense Index of Specifications and
Standards (DoDISS) specified in the solicitation.
MATERIAL:
Red Brass
DIMENSIONS:
DIAMETER: 5/8 inch (1.59 cm) (REF)
THICKNESS (At Thickest Point): 0.090 inch + 0.010 inch (0.229 cm +
0.025 cm)
FINISH:
Gold Plated, Matte Finish, Polished Highlights and shall match
TIOH Metal Finish Chip Number 8.
NOTES:
1. The term (REF) refers to the measurements taken from the
Government furnished hub or die.
AMSC N/A
FSC 8455
DISTRIBUTION STATEMENT A.
Approved for public release; distribution is unlimited.
1 of 2
