INCH-POUND
MIL-DTL-1563/14B
6 January 2014
SUPERSEDING
MIL-DTL-1563/14A
30 April 1997
DETAIL SPECIFICATION SHEET
INSIGNIA, U.S.M.A., CHAIN, HAT, CADET, FULL DRESS WITH POM POM
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this specification
sheet and the latest issue of MIL-B-1563.
MATERIAL: Aluminum
FINISH: Anodized Gold
MARKING FOR IDENTIFICATION: No Requirement
DEMENSION (Overall):
LENGTH: 11-9/16 inches + 1/8 inch (REF)
WIRE SIZE: 0.100 inch + .002 inch
SUGGESTED PACKIGING: Standard Commercial
UNIT PACKAGING: Each Wrapped.
INTERMEDIATE PACKAGING: 10 chains per box.
HAT CHAINS:
Hat chains shall conform to the style and dimensions shown.
CHANGES FROM PREVIOUS ISSUE: Marginal notations are not used in this revision to
identify changes with respect to the previous issue due to the extent of the changes.
AMSC N/A
Page 1 of 2
FSC 8455
