INCH-POUND
MIL-DTL-11589/5F
28 July 2010
SUPERSEDING
MIL-DTL-11589/5E
25 June 2007
DETAIL SPECIFICATION SHEET
RIBBON, SMALL ARMS MARKSMANSHIP, U.S. AIR FORCE
This specification is approved for use by all
Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification
sheet and the latest issue of MIL-DTL-11589.
COLOR PATTERN: REGULAR SIZE
FINISH: MOIRÉ
TOTAL
WIDTH OF STRIPES
FUNCTION
COLOR & CABLE NUMBER
WIDTH
INCHES & METRIC
OF STRIPES
STRIPES
FILLING YARN
1/32
0.8mm
Edge & Binder
Brittany Blue
HT
67119
7/32
5.6mm
Ground
Brittany Blue
HT
67119
1-3/8"
1/16
1.6mm
Ground
Air Force Yellow
HC
67103
White
(35.0mm)
3/4
19.0mm
Ground
Green
HAD
67129
HA 67101
1/16
1.6mm
Ground
Air Force Yellow
HC
67103
7/32
5.6mm
Ground
Brittany Blue
HT
67119
1/32
0.8mm
Edge & Binder
Brittany Blue
HT
67119
CHANGES FROM PREVIOUS ISSUE: Marginal notations are not used in this revision to
identify changes with respect to the previous issue due to the extent of the changes.
Custodians:
Preparing activity:
Army - IH
Army - IH
Air Force - 11
Review activity:
(Project No. 8455-2010-371)
DLA - CT
NOTE: The activities listed above were interested in this document as of the date of this
document. Since organizations and responsibilities can change, you should verify the currency of
the information above using the ASSIST Online database at https://assist.daps.dla.mil.
AMSC N/A
Page 1 of 1
FSC 8455
